Coatings

---

Thickness

.004"/.008"

.16 - .2 mm

Maximum Service Temperature

Continuous

500°F / 260°C

Intermittent

550°F / 287°c

Hardness

Tungsten Carbide

Rc 57

Fluoropolymer

55 Durometer

Porosity

0

Surface Finish

16-64 depending on customer need

Carbide Coating (RFS 1502F - Sheeter Draw Rolls)

Optimum operation of your sheeter is dependent upon traction being maintained between the sheet and the draw roll. The roll must be of the proper diameter to meter out the correct length of sheet. After several years of operation, the draw roll (or bull roll) can become worn or damaged by the doctor blade, and sheeter operation begins to suffer.

Racine Flame Spray, Inc. can help restore your sheeter to like new condition and operation. If the roll is not too badly damaged or out of true concentricity, we can apply a coating of tough, long lasting tungsten carbide to the roll. In this application, our RFS 1502F coating will last for many years providing superb traction and wear resistance. With minimal disassembly of the machine’s covers to allow access to the roll, we can coat most sheeter draw rolls in your facility in 4 to 5 hours on the machine.

If the roll has sustained damage or is badly out of round, we can grind it true and build up the O.D. to the proper diameter. We can then regrind the build-up layer and apply the tungsten carbide traction coating. We could also coat your spare roll in a lathe at your facility or in our specially designed stands.

Call us today at 1-800-225-7170 for more information, or to arrange a visit for a consultation at your facility by one of our engineers.

Ceramic Coating (Water Pan Rollers)

Racine Flame Spray offers a line of ceramic-coated water pan rollers for the printing industry. With the use of alcohol free solutions many printers are finding that our durable ceramic coated rolls are superior to the industry standard chrome plated rolls. The semi-porous microstructure of the plasma sprayed ceramic also makes it more hydrophilic than chrome, and provides a uniform layer of water across the roll.

With our Stainless Steel end caps and careful attention to manufacturing details, our water pan rolls will give you outstanding service in your presses, while providing outstanding corrosion protection. We will also make rolls to your specifications. Please call us to discuss this and other applications that you may have.

Ceramic/Fluoropolymer Coated (Palm Guides)

Racine Flame Spray, Inc. will either manufacture palm guides of stainless steel and coat them with our special long wearing RFS 5136T ceramic/fluoropolymer coating or we will apply our ceramic/fluoropolymer coating directly to your palm guides.

Ceramic/fluoropolymer coated palm guides are used today by many of our paper mill customers. The result is a longer wearing guide and longer life for paper machine clothing.

We currently stock several different sizes and configurations. You will appreciate the long wear and improved edge life of your felt.

Ceramic Coating (Corona Treater Rollers)

Racine Flame Spray is pleased to offer a new line of ceramic coatings for the corona treating industry. The coating is made from a premium quality aluminum oxide powder with a proprietary sealer to enhance its dielectric strength.

The coatings are available with nominal thickness’ of .050”, .070” and .090” (1.3, 1.8 and 2.3 mm) depending on the level of treatment required by the application. The coatings are designated CTR-500, CTR-700 and CTR-900 respectively. Rollers up to 24” diameter and 120” overall length can be coated and ground to an average roughness of 30-60 µin Ra (0.75-1.50 µm). Customers will find that prices are very competitive with those of other suppliers.

Please call us toll-free at 800-225-7170 for more information on the new ceramic coatings, as well as coatings for wear resistance, corrosion resistance, traction, dimension restoration and other requirements. We have earned an excellent reputation for the quality of our products and services, and are pleased to offer this new line of premium products.

Corrosion Resistant Coating (RFS 4103S)

Corrosion is a problem every papermaker must deal with since many of the process streams and surrounding environment are corrosive. Racine Flame Spray, Inc. has developed a corrosion resistant coating, RFS 4103S, that gives you the protection you need at a price that is affordable. RFS 4103S is an austenitic stainless steel (similar to 316 SS) with an organic sealer. The base coating is applied using an H.V.O.F. (High Velocity Oxygen Fuel) Process giving it high bond strengths and density. The sealer is then applied to fill any porosity and create an impervious barrier. This coating has excelled in felt roll applications where chrome plating was previously used. It is also recommended for protection against cavitation and particle erosion at temperatures less than 1,000 °F (540 °C)

--COATING PROPERTIES--

Thickness

Maximum Continuos Service Temperature

Hardness

Porosity

<0

Bond Strength

8,800 psi / 61 Mpa

Surface Finish

As Sprayed: 350-450 in 9-11 m
Sprayed and Sealed: 50-100 in 1.25-2.5 m

Corrosion Resistant Coating (RFS 1843, Corrosion and Mirror Finishes)

RFS 1843 is a tungsten carbide/cobalt/chrome coating that is sprayed through the High Velocity Oxygen Fuel (HVOF) thermal spray gun. The result is a tough durable coating that also affords a measure of corrosion resistance due to the presence of chromium.

This coating can be polished to a near mirror finish and has been used successfully on Kusters, Suction Press and Sym Rolls in paper mills. The unique properties of this coating also make it ideal for supercalendering, cast film extrusion and other applications.

--COATING PROPERTIES--

Thickness

Maximum Continuos Service Temperature

Hardness

HRc 68-70

Finish (as sprayed):

160-280 RMS

Finish (as ground):

10-15 RMS

Finish (as superfinished):

2-4 RMS

High Release Coating

Racine Flame Spray, Inc. is pleased to announce the launching of two new families of high release coatings. The new RSG and RSC coatings are designed primarily for use in the converting industry where durable, non-stick surfaces are required. Typical applications include coatings for idler rolls and components used in handling adhesives, hot plastics and other sticky materials.

The release coatings are applied over a thermally or plasma sprayed layer, yielding durable coatings with a wide range of surface textures. The RSG coatings are the premium products, with a tough gray silicone topcoat over a wear resistant metallized or ceramic base. The choice of base material would be determined primarily by electrical conductivity requirements.

The RSC coatings have a clear silicone topcoat with excellent release, but lower wear resistance than the gray coatings.

Another great feature is that many of these coatings can be applied at the customer's location, using Racine Flame Spray's extensive experience in doing on-site work. Racine Flame Spray has been providing thermal spray coatings to industry for over 25 years and has developed a reputation for excellent quality, reliability and service.

--COATING PROPERTIES--

RSG-M150

Metallized

Gray

100-200

58

Excellent

Moderate

400

500

yes

RSG-M350

Metallized

Gray

300-400

58

Excellent

Moderate

400

500

yes

RSG-M550

Metallized

Gray

500-600

58

Excellent

Moderate

400

500

yes

RSG-M750

Metallized

Gray

700-800

40

V. Good

Excellent

400

500

No

RSG-C250

Ceramic

Gray

200-300

58

Excellent

Excellent

400

500

No

RSG-C450

Ceramic

Gray

400-500

58

Excellent

Excellent

400

500

Yes

RSC-M150

Metallized

Clear

100-200

58

V.Good

Moderate

400

500

Yes

RSC-M350

Metallized

Clear

300-400

58

V.Good

Moderate

400

500

Yes

RSC-M550

Metallized

Clear

500-600

58

V.Good

Moderate

400

500

Yes

RSC-M750

Metallized

Clear

700-800

40

V.Good

Excellent

400

500

No

RSC-C250

Ceramic

Clear

200-300

58

V.Good

Excellent

400

500

No

RSC-C450

Ceramic

Clear

400-500

58

V.Good

Excellent

400

500

Yes

Composite Cores Coating (Lightweight Composite Rollers)

Composite rollers are noted for lightweight and high strength-to-weight ratios. They are ideally suited for applications where low inertia and high stiffness are required, typically in lines running at high speeds and with thinner webs. The lighter weight also makes them easier to handle and reduce operator injuries. They also result in less wear on bearings, bushings and journals.

Racine Flame Spray, Inc. offers composite rollers, shafts and cores with a variety of covering options. Wear resistant ceramic and metal matrix coatings are available with a wide range of surface properties. Select covers for wear resistance, release, traction, electrical conductivity and other characteristics.

Contact Racine Flame Spray, Inc. at 1-800-225-7170 for help in specifying lightweight composite rolls for your application. We have earned an excellent reputation for the quality of our products and services, and are pleased to offer this line of premium products.

Fluoropolymer Coatings

Racine Flame Spray, Inc. is pleased to offer a premier line of fluoropolymer coatings. These coatings combine the best in wear resistance, durability, low friction, release and ease of cleaning.

Typical applications include coatings for static turn bars, folder noses, folding bars, molds, cookware and many other uses. They work well with many types of adhesives and molten plastics, helping to reduce buildup and making the surfaces easy to clean.

The fluoropolymer coatings are applied over thermally sprayed metallic or ceramic base coats, yielding coatings that are durable with a variety of surface textures. The coatings are notable for their sparkling, brownish black appearance.

Racine Flame Spray has been providing thermal spray coatings to industry for over 25 years and has developed a reputation for excellent quality, reliability and service.

--COATING PROPERTIES--

RFK-M050

Metallized

Black

10-100

58

Excellent

V.Good

400

500

No

RFK-M150

Metallized

Black

100-200

58

Excellent

V.Good

400

500

No

RFK-M350

Metallized

Black

300-400

58

Excellent

Moderate

400

500

No

RFK-M550

Metallized

Black

500-600

58

Excellent

Moderate

400

500

No

RFK-C050

Ceramic

Black

10-100

58

Excellent

Excellent

400

500

No

RFK-C150

Ceramic

Black

100-200

58

Excellent

Excellent

400

500

No

RFK-C250

Ceramic

Black

200-300

58

Excellent

Excellent

400

500

No

RFK-C450

Ceramic

Black

400-500

58

Excellent

Excellent

400

500

No

RFN-M050

Metallized

Green

10-100

58

Excellent

V.Good

400

500

No

RFN-M150

Metallized

Green

100-200

58

Excellent

V.Good

400

500

No

RFN-M350

Metallized

Green

300-400

58

Excellent

Moderate

400

500

No

RFN-M550

Metallized

Green

500-600

58

Excellent

Moderate

400

500

No

RFC-M050

Metallized

Black Conductive

10-100

58

Excellent

V.Good

400

500

No

RFC-M150

Metallized

Black Cconductive

100-200

58

Excellent

V.Good

400

500

No

RFC-M350

Metallized

Black Conductive

300-400

58

Excellent

Moderate

400

500

No

RFC-M550

Metallized

Black Conductive

500-600

58

Excellent

Moderate

400

500

No

Top | Home

RFSK Fluoropolymer Coatings

--COATING PROPERTIES--

RFSK-M050

Metallized

Sparkling Blk

10-100

58

Excellent

V.Good

400

500

No

RFSK-M150

Metallized

Sparkling Blk

100-200

58

Excellent

V.Good

400

500

No

RFSK-M350

Metallized

Sparkling Blk

300-400

58

Excellent

Moderate

400

500

No

RFSK-M550

Metallized

Sparkling Blk

500-600

58

Excellent

Moderate

400

500

No

RFSK-C050

Ceramic

Sparkling Blk

10-100

58

Excellent

Excellent

400

500

No

RFSK-C150

Ceramic

Sparkling Blk

100-200

58

Excellent

Excellent

400

500

No

RFSK-C250

Ceramic

Sparkling Blk

200-300

58

Excellent

Excellent

400

500

No

RFSK-C450

Ceramic

Sparkling Blk

400-500

58

Excellent

Excellent

400

500

No

Metallic Coatings (RFS 7600E - Sealed Aluminum Coating)

If corrosion is a problem in the wet end of your paper machine, try RFS 7006E coating. This aluminum/epoxy coating provides dual protection against corrosion and is especially effective on fly rolls in the supercalendar section.

To create this coating, we spray an aluminum base coat with a 2-part epoxy sealer over it. The sealer is then cured to create an inert barrier.

This coating is a great replacement for the white paint used by most O.E.M.'s because even if the sealer wears out, there is the aluminum base coat to provide corrosion protection.

Below are the specifications for the coating. Please call us for a FREE sample, or if you have any questions regarding this product.

--COATING PROPERTIES--

Coating thickness:

.006"/.010"

Max. Cont. Service Temp:

250°F

Surface finish:

100-200Ra

Metallic Coatings (RFS 3015R - On-Site Dryer Can Coating)

We offer RFS 3015R as an alternative to fluoropolymer sleeves that are very delicate and easily damaged, and fluoropolymer impregnated coatings, which are expensive and cannot be done on-site.

This coating can be sprayed on-site, provided that the can is accessible. The 1st and 2nd cans after the size press are usually easily done. For cans other than the 1st or 2nd, we will send one of our qualified Sales Technicians to your mill to inspect the installation and discuss the possibilities with you.

The coating is a nickel-chrome-boron alloy, with a silicone release agent sprayed on immediately afterwards. This result in a long lasting durable release coating that can be doctored. Best of all, most cans can be coated in 8-10 hours!

--COATING PROPERTIES--

Coating thickness:

.003"/.004"

Max. Continuous Service Temp:

1,500°F

Hardness:

62 Hrc

Surface finish:

200-300 µin Ra

Traction Coatings

Racine Flame Spray, Inc. offers traction coatings for handling a wide variety of webs and process materials. Paper types from LWC to recycled linerboard.

Applications

• Winder Drums
• Reel Drums
• Re-Reelers
• Felt Rolls
• Segmented Slitter Guide Rolls
• Sheeter Draw Rolls

Benefits

• Eliminate Slippage
• Ensure Tight Starts
• Eliminate Star Bursts
• Reduce Crepe Wrinkles
• Eliminate Telescoping
• Reduce Offsetting

Convenience

• Coatings can be applied on-site in the machine without removing the rolls.
• Almost any roll can be coated in less than 12 hours.

Service

• Our patented traction analyzer can help you determine when your coating needs to be re-worked.

Also Available

• On-Site release coatings for winders, reel drums and dryer cans (first two cans after size press).
• In-House high-temperature fluoropolymer coatings for dryers, felt rolls, etc.
• Sealed aluminum coatings for corrosion resistance.
• Ceramic coatings for palm guides.
• Ultra-dense carbide coatings for supercalendar rolls.

Call us today at 1-800-225-7170 for more information, or to arrange a visit for a consultation at your facility by one of our engineers.
